Specifications
Features
- AGO standard console design with 32-note radiating concave pedalboard
- Hymn Player with 350 popular hymn tunes including introduction and verses
- Velocity-sensitive pedalboard for timpani and other orchestral effects
- Self-contained, self-adjusting pedalboard design eliminates risk of malfunction on uneven flooring
- No special hardware needed to add external speakers
- Pipe compatible
- Expanded voicing menus
- Simulated dark Piedmont oak case
- Locking rolltop
- Simple, easy-to-play design
- Practice mode with built-in demo songs
- Record/playback with music storage
- USB data storage for registrations and song data
- Satellite speakers: 2 x 15 watts
- NEXT and PREVIOUS piston sequencer recall
- 9 historic temperaments
- Tuning control
- M+, M-
- -6/+5 transposer
- RSS room modeling
- Stereo headphone jack
- MIDI in/out
- Pipe organ modeling technologies
- Bass coupler
- Melody coupler
Specification
| Engraved Stop | Voice Palette 1 | Voice Palette 2 | Voice Palette 3 |
|---|---|---|---|
| MANUAL I | |||
| Bourdon 16' | Violone 16' | Principal 16' | Quintaton 16' |
| Principal 8' | Open Diapason 8' | Montre 8' | Prinzipal 8' |
| Gemshorn 8' | 2nd Diapason 8' | Voce Umana II 8' | Aeoline 8' |
| Gedackt 8' | Clarabella 8' | Fl?e Harmonique 8' | Bourdon 8' |
| Octava 4' | Principal 4' | Fl?e ?Bec 4' | Fugara 4' |
| Quinte 2-2/3' | Twelfth 2-2/3' | Nazard 2-2/3' | Quintaden 8' |
| Superoctav 2' | Fifteenth 2' | Doublette 2' | Piccolo 2' |
| Mixtur IV | Tierce Mixture V | Cornet V | Rauschquint IV |
| Trumpet 8' | Waldhorn 8' | Trompette 8' | Cromorne 8' |
| Chimes (piston) | |||
| Tremulant (piston) | |||
| MANUAL II | |||
| Still Gedackt 8 | Stopped Diapason 8' | Bourdon 8' | Rohrgedackt 8' |
| Spitz Geigen 8' | Geigen Diapason 8' | Salicional 8' | Viola 8' |
| Viola C?este II 8' | Flute Celeste II 8' | Voix C?este II 8' | Schwebung II 8' |
| Principal 4' | Unda Maris II 4' | Prestant 4' | Muted Viols II 4' |
| Nachthorn 4' | Solo Flute 4' | Fl?e Traversi?e 4' | Spillfl?e 4' |
| Nasat 2 2/3' | Twelfth 2-2/3' | Nazard 2-2/3' | Quinte 2-2/3' |
| Piccolo 2' | Wald Flute 2' | Doublette 2' | Schwegel 2' |
| Sesquialtera II | Dolce Cornet II | Tierce 1-3/5' | Larigot 1-1/3' |
| Mixture III | Cymbale III | Plein Jeu IV | Siffl?e 1' |
| Schalmei 8' | Oboe 8' | Hautbois 8' | Trompette 8' |
| Tremulant (piston) | |||
| PEDAL | |||
| Principal 16' | Open Wood 16' | Contrabass 16' | Violone 16' |
| Subbass 16' | 2nd Subbass 16' | Bourdon 16' | Quintaton 16' |
| Octava 8' | Octave 8' | Montre 8' | Violoncello 8' |
| Bourdon 8' | Stopped Flute 8' | Fl?e 8' | Still Gedackt 8' |
| Choral Bass 4' | Fifteenth 4' | Fl?e de Bois 4' | Quintfl?e 10-2/3' |
| Posuane 16' | Trombone 16' | Bombarde 16' | Basson 16' |
| Trompete 8' | Trumpet 8' | Trompette 8' | Dulzian 8' |
| Klarine 4' | Cornet Clarion 4' | Clairon 4' | Schalmei 4' |
124 Built-in User Voices
The User Voices are accessed through the display and are assignable to any of the two User/MIDI controls per division.
| 92 Pipe Organ Voices | |
001 Principal 32' 002 Contra Geigen 32' 003 Contra Bourdon 32' 004 Spitz Prinzipal 16' 005 Lieblich Gedackt 16' 006 Dulciana 16' 007 Cellos C?estes II 16' 008 Erzhaler C?estes II 16' 009 Montre 8' 010 Bach Principal 8' 011 Gemshorn 8' 012 Gamba 8' 013 Dulciana 8' 014 Holzgedackt 8' 015 Gross Flute 8' 016 2nd Flute Harmonique 8' 017 C?estes III 8' 018 Unda Maris III 8' 019 Principal 4' 020 Open Flute 4' 021 Chimney Flute 4' 022 Quinte 2-2/3' 023 Nazard 2-2/3' 024 Gemshorn 2' 025 Piccolo 2' 026 Tierce 1-3/5' 027 Larigot 1-1/3' 028 Septi?e 1-1/7' 029 Siffl?e 1' 030 Jeu de Clochette II 031 Quartane II 032 Scharf II 033 Gabler Cornet V 034 Pedal Grand Mixtur VI 035 Grave Mixtur IV 036 2nd Grave Mixtur IV 037 Fourniture San Sulpice IV-VI 038 Tierce Fourniture VI 039 Grand Mixtur VIII 040 Double Ophicleide 32' 041 Contre Bombarde 32' 042 Contre Bassoon 32' 043 2nd Bombarde 16' 044 Contre Trompette 16' 045 Rankett 16' 046 Trompet 8' | 047 Trompette 8' 048 2nd Trompette 8' 049 State Trumpet 8' 050 Chamades 8' 051 Dulzian 8' 052 Cromorne 8' 053 Baryton 8' 054 Cor d?mour 8' 055 Regal 8' 056 Vox Humana 8' 057 Vox Humaine 8' 058 Vox Humaine Trem 8' 059 Clarion 4' 060 Clairon 4' 061 2nd Clairon 4' 062 Rohrschalmei 4' 063 Principals III 8'+4'+2' 064 Principals+Mixturs 8'+4'+2'+IV 065 Flute C?estes IV 16'+4' 066 C?estes IV 16'+4' 067 C?estes VI 16'+8'+4' 068 C?estes VII 16'+8'+4'+Vox 069 Voxes II 16'+8' 070 Voxes II 16'+4' 071 Full Swell 16'+8'+4'+Reeds 072 Tibia 8' 073 Tibia 4' 074 VDO Celeste 8' 075 VDO Celeste Trem 8' 076 Tuba Trem 8' 077 Cornopean Trem 8' 078 Tibias 16'+8'+Vox 16'+8' 079 Full Tibias+Strs 8'+4' 080 Vox & Str 16'+Tib 2'+Quint 081 Vox 16'+8'+Celetes 8' 082 Tibias 8', 4'+Str 083 Tibias 8', 4'+Str+Vox 084 Tibias 8', 4'+Tuba 8' 085 Tibia 4'+Celestes 8' 086 Tibias 4', 2'+Str 16', 8' 087 Tibia 4'+Kinura 8' 088 Str 8'+Tibias 2'+Glocken 089 Tibia 4'+Glockenspiel 090 Organ Harp 8' 091 Chrysoglott 4' 092 Tracker/Barker Noise |
| 32 Orchestral Voices | |
001 Grand Piano 002 Elec Piano 003 Harpsichord 8 I 004 Harpsichord 8 II 005 Harpsichord 4 006 Harpsichord Lute 007 Harpsichord 8+8 008 Harpsichord 8+4 009 Celesta 010 Orchestral Harp 011 Drawbar 1 012 Drawbar 2 013 Guitar 014 Acoustic Bass 015 String Ensemble 016 Slow Strings | 017 Octave Strings 018 Slow Violin/Cello 019 Saxophone 020 Orchestral Trumpet 021 Brass Ensemble 022 French Horn Section 023 Orchestral Flute 024 Orchestral Oboe 025 Orchestral Clarinet 026 Choir Aahs 027 Choir Oohs 028 Organ Chimes 029 Tubular Bells 030 Tower Chimes 031 Handbells 032 Timpani |
Available options:
- Tracker touch keyboards
- Interface to existing or new pipes
Size and weight
Rodgers maintains a policy of continuous improvement on its instruments and therefore reserves the right to change specifications without notice or obligation.
