| Rated Power Output | | 30W + 30W |
|
| Nominal Input Level (1 kHz) | | GUITAR Channel: -10 dBu, MIC/LINE Channel: -50/-10 dBu, AUX IN: -10 dBu |
|
| Nominal Output Level (1 kHz) | | DI/TUNER OUT: +4 dBu, LINE OUT: +4 dBu, SUB WOOFER OUT: +4 dBu |
|
| Speakers | | 16.5 cm (6.5 inches) x 2 |
|
| Controls | | [GUITAR Channel] PICKUP Switch (PIEZO/MAGNETIC), SHAPE Switch, VOLOME knob, Equalizer knobs (BASS, MIDDLE, TREBLE), CHORUS Switch [MIC/LINE Channel] PHANTOM Switch, SELECT Switch (MIC/LINE), VOLUME Knob, Equalizer knobs (BASS, MIDDLE, TREBLE), CHORUS Switch, [CHORUS Knob] [REVERB/DELAY Knob] [ANTI-FEEDBACK] FREQUENCY knob, START Button [MUTE Switch] [MASTER Knob] [POWER Switch] |
|
| Indicator | | CHORUS (GUITAR Channel, MIC/LINE Channel), ANTI-FEEDBACK, MUTE, POWER |
|
| Connectors | | GUITAR Channel Input Jack (1/4-inch phone type), MIC/LINE Input Jack (XLR type, 1/4-inch phone type), AUX IN Jacks (RCA phono type, 1/4-inch phone type), DI/TUNER OUT Jack (1/4-inch TRS phone type), LINE OUT Jacks (XLR type, 1/4-inch phone type), SUB WOOFER OUT Jack (1/4-inch phone type), PHONES Jack (1/4-inch TRS phone type), FOOT SWITCH Jack (1/4-inch TRS phone type) |
|
| Power Supply | | AC 117/230/240 V |
|
| Power Consumption | | 68 W |
|
| Accessories | | Owner's Manual, Soft Case |
|
| Options | | Foot Switch: BOSS FS-5U, BOSS FS-5L (Mute On/Off), Connection Cable: PCS-31 |
|
Size and Weight |
| Width | | 380 mm |
 |
| Depth | | 270 mm |
|
| Height | | 268 mm |
|
| Weight | | 9.8 kg 21 lbs. 10 oz. |
|
