제품사양
- General Pistons: 10
Divisional Pistons: 5 Great, 5 Swell, 5 Choir
Toe Pistons: 10 configurable
Couplers: 3 plus 8 User/MIDI Controls
Bass, Melody II and Melody I Couplers
Tremulants: 4 including Flute Alt Tremulant
Shoes: 2 Expression, Crescendo
Memory: 20 levels per piston
- Traditional wood veneer cabinet with deluxe wood tambour, built in the USA
- Choice of three finish colors
- Tab stop controls
- "Practice assistant" mode with over 40 built-in demo songs
- Record/playback
- USB-enabled for unlimited storage of registration data and saved performances
- Hymn Player automatically plays 350 built-in hymns with introduction & verse
- Music storage bench in matching finish
- Rolltop lock
- Velocity-sensitive “Ivory Feel” keyboards - tracker touch option available
- 32-note radiating AGO pedalboard
- Self-contained pedalboard mechanism for greater reliability on uneven flooring or carpeting
- Programmable kick switch
- Memory +/- pistons
- PREV/NEXT piston sequencer recall
- 9 historic temperaments
- Tuning control
- -6/+5 transposer
- RSS room modeling
- STOP, PLAY, REC pistons
- Stereo headphone jack
- MIDI in/out and Local Off
- 4 channel internal audio system: 2 channels x 50 watts plus 2 channels x 15 watts (satellite speakers)
- 2 to 12 channel external audio option
- Onboard voicing finishing and leveling controls
- Pipe organ modeling technologies
- Pipes off
- Ancillary on
- Manual I/Pedal Enclosed
- Organ Type piston instantly activates American Eclectic, English Cathedral, French Romantic or German Baroque stops
- Adjustable tremulants
- Separate dimmer controls for console lighting and tabs/pistons
샘플사양
| CHOIR | COUPLERS: III/I (SW TO CH) | ||
| Spitz Principal 8' | Montre 8' | English Diapason 8' | Geigen 8' |
| Still Gedackt 8' | Bourdon 8' | Stopped Diapason 8' | Rohr Gedackt 8' |
| Unda Maris II 8' | Erzähler Céleste II 8' | Muted Viols II 8' | Viol Céleste II 8' |
| Spitzflöte 4' | Cor De Nuit 4' | Flûte d'Amour 4' | Principal 4' |
| Principal 2' | Doublette 2' | Schwegel 2' | Flachhflöte 2' |
| Quinte 1 1/3' | Nineteenth 1 1/3' | Twelfth 2 2/3' | Nazard 2 2/3' |
| Sesquialtera II | Dolce Cornet II | Cornet des Violes III | Jeu de Clochette II |
| Mixtur III | Quartane II | Grave Mixture IV | Sifflöte 1' |
| Cromorne 8' | Clarinette 8' | Baryton 8' | Bärpfeife 8' |
| Fanfare Trumpet 8' | Royal Tuba 8' | Tromba 8' | Trompet II 16'+8' |
| Tremulant | |||
| GREAT | COUPLERS: I/II (CH TO GT), III/II (SW TO GT) | ||
| Violone 16' | Principal 16' | Bourdon 16' | Quintaton 16' |
| Principal 8' | Open Diapason 8' | Montre 8' | Prinzipal 8' |
| Gemshorn 8' | 2nd Diapason 8' | Voce Umana II 8' | Aeoline 8' |
| Gedackt 8' | Clarabella 8' | Flûte Harmonique 8' | Bourdon 8' |
| Octava 4' | Principal 4' | Flute à Bec 4' | Fugara 4' |
| Quinte 2 2/3' | Twelfth 2 2/3' | Nazard 2 2/3' | Quintaden 8' |
| Superoctav 2' | Fifteenth 2' | Doublette 2' | Piccolo 2' |
| Mixtur IV | Tierce Mixture V | Cornet V | Rauschquint IV |
| Trumpet 8' | Waldhorn 8' | Trompette 8' | Krumhorn 8' |
| Tremulant | |||
| Chimes | |||
| Zimbelstern | |||
| SWELL | |||
| Geigen Diapason 8' | Spitz Principal 8' | Salicional 8' | Viola 8' |
| Bourdon 8' | Flûte Harmonique 8' | Flûte Douce 8' | Quintadena 8' |
| Viola Celeste II 8' | Flûte Céleste II 8' | Voix Céleste II 8' | Schwebung II 8' |
| Principal 4' | Unda Maris II 4' | Prestant 4' | Muted Viols II 4' |
| Flûte traversière 4' | Solo Flute 4' | Flûte Céleste II 4' | Nachthorn 4' |
| Nasat 2 2/3' | Twelfth 2 2/3' | Nazard 2 2/3' | Quinte 2 2/3' |
| Piccolo 2' | Fifteenth 2' | Doublette 2' | Octavin Harmonique 2' |
| Tierce 1 3/5' | Seventeenth 1 3/5' | Terz 1 3/5' | Terz Fluit 1 3/5' |
| Plein Jeu IV | Grave Mixtur III | Fourniture V | Scherp III |
| Basson 16' | Double Trumpet 16' | Bombarde 16' | Dulzian 16' |
| Hautbois 8' | Oboe 8' | Trompette 8' | Schalmei 8' |
| Tremulant | |||
| PEDAL | COUPLERS: I/P (CH TO PD), II/P (GT TO PD), III/P (SW TO PD) | ||
| Montre 32' | Contra Geigen 32' | Contre Bourdon 32' | Untersatz 32' |
| Principal 16' | Open Wood 16' | Contrebasse 16' | Violone 16' |
| Subbass 16' | Lieblich Gedackt 16' | Bourdon 16' | Quintaton 16' |
| Octava 8' | Octave 8' | Montre 8' | Violoncello 8' |
| Bourdon 8' | Stopped Flute 8' | Flûte 8' | Still Gedackt 8' |
| Choral Bass 4' | Fifteenth 4' | Flûte 4' | Quint Flöte 10 2/3 |
| Posaune 16' | Trombone 16' | Bombarde 16' | Basson 16' |
| Trompete 8' | Trumpet 8' | Trompette 8' | Dulzian 8' |
| Klarine 4' | Cornet Clarion 4' | Clairon 4' | Schalmei 4' |
Available options
- Tracker touch keyboards
- Classic trim on console sides
- Interface to existing or new pipes
Size and Weight
- Console dimensions:
Height: 124.84 cm (49.15”)
Width: 148.1 cm (58.3”)
Depth: 60.8 cm (23.94”)
Depth with pedalboard: 122.79 cm (48.34”)
Weight:161.03 kg (355 lbs) - Bench: Height 66.93 cm (26.35”); Width 122.03 cm (48.04”); Depth 35.6 cm (14.02”). Weight 24.95 kg (55 lbs)
- Pedalboard: Weight: 43.5 kg (96 lbs)
- Total Unboxed Weight: Console, speakers, pedalboard & bench 229.52 kg 506 lbs
- Organ Manuals: 3 Manuals.
- Organ Controls: Tab
- Control Type Options: Lighted
