제품사양
- 2 manuals, 29 stop positions, 48 Voice Palette stops = 77 total stops equivalent to 90 pipe ranks
- PerformanceTouch keyboards
- USB memory
- 100 internal memory levels
- Record/playback
- Parallel Digital Imaging?? sound generation
- RSS room modeling technology for acoustic control
- Full compatibility with speaking pipes
- 8 selectable historic temperaments
- Transposer
- Master volume control
- Stereophonic headphone jack
- Lift-lid storage bench
샘플 사양
| Engraved Stop | Voice Palette 1 | Voice Palette 2 | Voice Palette 3 |
| GREAT | |||
| Diapason 8 | Principal 8 | Gemshorn 8 | |
| Chimney Flute 8 | Holz Gedackt 8 | Harmonic Flute 8 | Doppelflute 8 |
| Unda Maris II 8 | Flûte Céleste II 8 | Viols Chorus IV | |
| Octave 4 | Principal 4 | Unda Maris II 4 | |
| Waldflute 4 | Koppelflöte 4 | ||
| Twelfth 2-2/3 | |||
| Fifteenth 2 | Piccolo 2 | ||
| Fourniture V | Scharf IV | Quint Flute 1-1/3 | |
| Tromba 8 | Clarinet 8 | Cremona 8 | Festival Trumpet 8 (SW) |
| Chimes | Harp | Harpsichord | |
| Tremulant | |||
| Zimbelstern | |||
| Swell to Great | |||
| MIDI GT A, B | |||
| SWELL | |||
| Lieblich Gedackt 16 | Viola 16 | ||
| Bourdon 8 | Concert Flute 8 | Flute Harmonic 8 | |
| Viola de Gamba 8 | Principal 8 | Dulciana 8 | |
| Viola Céleste 8 | Viol Céleste II 8 | Muted Viols II 8 | |
| Prestant 4 | Viol Octave 4 | Violinas II 4 | |
| Flûte Traversière 4 | Orchestral Flute 4 | ||
| Octavin 2 | Principal 2 | ||
| Chorus Mixture IV | Cornet II | Nazard 2-2/3 | Tierce 1-3/5 |
| Double Trumpet 16 | Contre Trompette 16 | Basson 16 | |
| Trumpet 8 | Oboe 8 | Orchestral Oboe | Festival Trumpet 8 |
| Tremulant | |||
| Swell Unison Off | |||
| MIDI SW A, B | |||
| PEDAL | |||
| Bourdon 32 | Geigen 32 | ||
| Principal 16 | Violone 16 | ||
| Bourdon 16 | Subbass 16 | Lieblich Gedackt 16 | |
| Octave 8 | Gemshorn 8 | ||
| Gedackt Bass 8 | Flute 8 | ||
| Choralbass 4 | Nachthorn 4 | Clarion 4 | Rohrschalmei 4 |
| Bombarde 16 | Trombone 16 | Basson 16 (SW) | |
| Trumpet 8 | |||
| Great to Pedal | |||
| Swell to Pedal | |||
| MIDI PD A, B |
Shoes (all with indicators)
- Great expression
- Swell expression
- Crescendo
Lighted Pistons
- 2 MIDI pistons per keyboard
- All Expr. Swell
- Flute Trem Alt.
- Bass and Melody couplers
- Full Organ thumb piston
Combination Action
- 10 general thumb pistons
- 5 divisional thumb pistons each for Swell, Great and Pedal
Size and Weight
- CONSOLE DIMENSIONS: 122.8 cm height x 148.6 cm width x 125.4 cm depth with pedalboard; depth without pedalboard: 76.7 cm
- WEIGHT (approx.): Console: 263.6 kg, bench: 25 kg, pedalboard:50 kg. Actual weight will vary depending on console options ordered.
Audio System
Bi-amplified audio with minimum 5 channels and 5 Rodgers Audiophile speakers. Custom speaker installations, antiphonal divisions and increased channeling are optional.
Rodgers maintains a policy of continuous improvement on its instruments and therefore reserves the right to change specifications without notice or obligation.
